Main Specifications
Product Description
Cisco UCS Smart Play 8 C240 M4 SFF Performance - rack-mountable - Xeon E5-2660V3 2.6 GHz - 32 GB - no HDD
Type
Server - rack-mountable
Height (Rack Units)
2U
Server Scalability
2-way
Processor
2 x Intel Xeon E5-2660V3 / 2.6 GHz (, up to 3.3 GHz, (10-core)
Processor Socket
LGA2011-v3 Socket
Processor Main Features
Hyper-Threading Technology, Intel Turbo Boost Technology 2
Cache Memory
50 MB L3 cache
Cache Per Processor
25 MB
RAM
32 GB (installed) / 384 GB (max) - DDR4 SDRAM - ECC - PC4-17000
Storage Controller
RAID (SATA 6Gb/s / SAS 6Gb/s) - PCIe 3.0
Server Storage Bays
Hot-swap 2.5"
Hard Drive
No HDD
Optical Storage
No optical drive
Graphics Controller
Matrox G200e
Video Memory
8 MB
Networking
1GbE
Power
AC 120/230 V (50/60 Hz)
Power Redundancy
Yes
OS Provided
No operating system
Dimensions (WxDxH)
17.6 in x 29.1 in x 3.4 in
Pricing Type
Remanufactured
General
Type
Server
Product Form Factor
Rack-mountable - 2U
Server Scalability
2-way
Hot-Swap Bays Qty
8
Expansion / Connectivity
Bays
8 (total) / 8 (free) x hot-swap 2.5" SFF
Slots
1 (total) / 1 (free) x PCIe 3.0 x24 - three-quarter-length, full-height (x8 mode) ¦ 1 (total) / 1 (free) x PCIe 3.0 x24 - full-length, full-height (x16 mode) ¦ 1 (total) / 1 (free) x PCIe 3.0 x16 - full-length, full-height (x8 mode) ¦ 2 (total) / 1 (free) x SD card
Interfaces
2 x USB 3.0 (2 rear) ¦ 1 x VGA (1 rear) ¦ 1 x serial - RJ-45 (1 rear) ¦ 2 x LAN (Gigabit Ethernet) - RJ-45 (2 rear) ¦ 1 x management (NIC) - RJ-45 (1 rear) ¦ 1 x KVM (1 in front)
Miscellaneous
Included Accessories
2 x CPU Heatsink, rack rail kit, riser card, 32 GB SD Memory Card
Compliant Standards
CISPR 22 Class A, BSMI CNS 13438 Class A, CISPR 24, EN 61000-3-2, EN 61000-3-3, EN55024, AS/NZS 60950-1, ICES-003 Class A, UL 60950-1, UL 60950-1 Second Edition, Directive 2004/108/EC, CSA C22.2 No. 60950-1 Second Edition, EN 60950-1 Second Edition, IEC 60950-1 Second Edition, Directive 2006/95/EC, KN24, KN22 Class A, GB4943.1-2001, EN 55022 Class A, EN 300 386
Pricing Type
Remanufactured
RAM
Installed Size
32 GB / 384 GB (max)
Technology
DDR4 SDRAM - ECC
Effective Memory Speed
2133 MHz
Rated Memory Speed
2133 MHz
Memory Specification Compliance
PC4-17000
Form Factor
DIMM 288-pin
Slots
24 (total) / 22 (empty)
Features
Registered, dual rank
Configuration Features
2 x 16 GB
RAM Supported
384 GB registered - ECC ¦ 768 GB Load-Reduced - ECC
Networking
Ethernet Ports
2 x Gigabit Ethernet
Ethernet Controller
Intel I350
Data Link Protocol
Ethernet, Fast Ethernet, Gigabit Ethernet
Power
Device Type
Power supply - hot-plug
Power Redundancy
Yes
Power Redundancy Scheme
1+1
Installed Qty
2
Max Supported Qty
2
Voltage Required
AC 120/230 V (50/60 Hz)
Power Provided
1200 Watt
Environmental Parameters
Min Operating Temperature
41 °F
Max Operating Temperature
95 °F
Humidity Range Operating
10 - 90% (non-condensing)
Storage Controller
Type
1 x RAID - PCIe 3.0
Controller Interface Type
SATA 6Gb/s / SAS 6Gb/s
Channel Qty
8
RAID Level
RAID 0, RAID 1, RAID 10, JBOD
Cache Memory
Installed Size
L3 cache - 50 MB
Cache Per Processor
25 MB
Optical Storage
Type
No optical drive
Monitor
Monitor Type
None.
Graphics Controller
Graphics Processor
Matrox G200e
Video Memory
8 MB
Video Interfaces
VGA
Operating System / Software
OS Provided
No operating system
Hard Drive
Type
No HDD
Dimensions & Weight
Width
17.6 in
Depth
29.1 in
Height
3.4 in
Card Reader
Supported Flash Memory Cards
SD Memory Card
Processor / Chipset
CPU
Intel Xeon E5-2660V3
Clock Speed
2.6 GHz
Max Turbo Speed
3.3 GHz
Number of Cores
10-core
CPU Qty
2
Max CPU Qty
2
Processor Main Features
Hyper-Threading Technology, Intel Turbo Boost Technology 2
CPU Socket
LGA2011-v3 Socket
Chipset Type
Intel C612
