Wireless access point - Wi-Fi 5 - 2.4 GHz, 5 GHz
| Main Specifications | |
|---|---|
| Product Description | Cisco Aironet 1562I - wireless access point - Wi-Fi 5 |
| Device Type | Wireless access point |
| Form Factor | External - outdoor |
| Localization | Bahrain, Egypt, Pakistan |
| Data Link Protocol | IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac Wave 2 |
| Frequency Band | 2.4 GHz, 5 GHz |
| Capacity | Spatial streams: 2 |
| Power Over Ethernet (PoE) Supported | UPOE |
| Dimensions (WxDxH) | 6.7 in x 3.9 in x 9 in |
| Weight | 5.51 lbs |
| Manufacturer Warranty | 1-year warranty |
| General | |
| Device Type | Wireless access point |
| Ruggedized Design | Outdoor |
| Width | 6.7 in |
| Depth | 3.9 in |
| Height | 9 in |
| Weight | 5.51 lbs |
| Localization | Bahrain, Egypt, Pakistan |
| Expansion / Connectivity | |
| Interfaces | 1 x 1000Base-T - RJ-45 (WAN) ¦ 1 x - SFP (mini-GBIC) ¦ 1 x management - RJ-45 |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 1 year |
| Miscellaneous | |
| Compliant Standards | EN 60950, IEC 60529 IP67, FCC Part 15.247, RSS-210, RSS-102, EN 61000-4-4, EN 61000-4-2, EN 61000-4-3, EN 61000-4-5, NEMA Type 4X, FCC Part 15.107, FCC Part 15.109, FCC Part 15.407, ARIB STD-T66, ARIB STD-T71, MIL-STD-810, EN 300 328, FCC OET Bulletin 65c, EN 301 489-1, AS/NZS 4268.2003, ANSI / IEEE 587 C62.41, NEMA 250-2008, EN 60068-2-5, UL 60950 Second Edition, IEC 60950 Second Edition, EN 60950 Second Edition, EN 301 893 |
| Networking | |
| Form Factor | External |
| Connectivity Technology | Wireless |
| Data Transfer Rate | 1.3 Gbps |
| Data Link Protocol | IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac Wave 2 |
| Network / Transport Protocol | L2TP, IPSec |
| Frequency Band | 2.4 GHz, 5 GHz |
| Capacity | Spatial streams: 2 |
| Features | Auto-sensing per device, MAC address filtering, DFS support, VPN passthrough, reset button, 2T2R MIMO technology, ClientLink technology, 3T3R MIMO technology, radio resource management (RRM), cyclic shift diversity (CSD), beamforming technology, packet aggregation A-MPDU, packet aggregation A-MSDU, Dynamic path selection (DPS), MAC address authentication |
| Encryption Algorithm | LEAP, AES, TLS, PEAP, TTLS, WPA, WPA2 |
| Authentication Method | X.509 certificates, Extensible Authentication Protocol (EAP) |
| Compliant Standards | IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.1x, IEEE 802.11i, IEEE 802.11n, IEEE 802.3at, IEEE 802.11ac Wave 2 |
| Power | |
| Power Over Ethernet (PoE) Supported | UPOE |
| Environmental Parameters | |
| Min Operating Temperature | -40 °F |
| Max Operating Temperature | 149 °F |
| Humidity Range Operating | 5 - 95% (non-condensing) |
| Antenna | |
| Antenna | Internal |
| Directivity | Omni-directional |
